VALVE AMICO R2
Technical characteristics
1 zone / 2 zones
Inlet thread ¾”-1” F
Outlet thread ¾” M
Min bar 1.0 bar
Max working pressure 6.0 bars
Min flow 5 l/min
Max fl ow 40 l/min
Diaphragm 9 Vdc electric valve
Removable control unit
ABS Body
Hard plastic cover for LCD display protection
Wide backlit 3” LCD display
Electrical Power Supply 2x1.5 V AA alkaline batteries (not included)
Rain sensor input (jack connection)
CODICI
200.4042520 RICAMBIO ELETTROVALVOLA AMICO R2/AMICO D2
Complete user-friendly programming
1 program
Run time min/max: 1/240 minutes
Watering frequency: from every 6 hours up to once 15 days
One look display:
Current time indication
Start time indication
Duration of watering indication
Frequency indication
Next irrigation indication
Watering countdown
Low battery function
