TURBINA VISION

Inlet thread: 1"M
Outlet thread: 1"M
IP68 Recharge output compatible with Vision and Rechargeable devices
Maximum voltage generated: 6.8 Vdc
Maximum power generated: 2 W
Body material: PA6 30% fibreglass
IP68
4 different nozzles to adapt to any irrigation system: 33% - Low Flow rate: from 10 to 18 l/min (suggested) 66% - Medium Flow rate: from 16 to 30 l/min (suggested) 80% - High Flow rate: from 24 to 36 l/min (suggested) 100% - Top Flow rate: from 30 to 50 l/min (suggested)
Maximum flow: 70 l/min
Min. working pressure: 1 bar
Max. working pressure: 6 bar
Operation Temperature: 4-70°C
Dimensions: 120 mm x 49 mm x 65 mm
Weight: 400 g

SELF SUSTAINABLE

SAVE TIME AND MONEY

The recharging Vision System  keeps batteries charged, reducing time and expense of maintaining our installation.

ECO FRIENDLY

GREEN ECONOMY

The Green Economy, renewable energies represent an authentic cultural revolution, which can make us free to produce hazardous waste and difficult to dispose, with all the consequences.

MADE IN ITALY

The Vision system is a project 100% created in Italy. The entire design, development and testing phase takes place within our company, which is committed to maintaining high quality and environmental standards, starting with the selection of high-level components and ending with scrupulous testing. Following the whole process of development and realization, we are able to guarantee the full reliability of the product, ensuring a valid after-sales support able to quickly satisfy any need or problem.

4 different nozzles to adapt to any irrigation system:
33% - Low Flow rate: from 10 to 18 l/min (suggested)
66% - Medium Flow rate: from 16 to 30 l/min (suggested)
80% - High Flow rate: from 24 to 36 l/min (suggested)
100% - Top Flow rate: from 30 to 50 l/min (suggested)
Body material: PA6 30% fibreglass
4 different nozzles to adapt to any irrigation system:
IP68 Recharge output compatible with Vision and Rechargeable devices
2 poles IP68 female quick connector (max diameter: 18 mm)
